Humanoid robots are a next-generation robot platform capable of taking on a wide range of tasks in place of people, and the scope of where they can be used keeps growing. As their potential applications expand from manufacturing and logistics into service industries as well, research and development aimed at putting them to work in real-world settings is moving forward at a fast pace.
Still, replicating human-like movement remains a difficult challenge. Moving and balancing reliably across a variety of work environments takes more than sensors and control technology; it also requires drive technology that can translate all of that into actual motion. Bipedal walking in particular, the kind of natural, human-like movement people take for granted, is one of the hardest capabilities to achieve in humanoid robot development.
Making this possible depends on the actuators built into a humanoid’s joints meeting a range of demanding requirements. Backdrivability plays an especially important role here, helping absorb the impact and load that build up during walking.
In this article, we’ll look at why backdrivability matters so much in humanoid robot development and what actuator requirements are placed on the joints of a bipedal walking robot.
What Is Backdrivability? Concept and Key Characteristics
Actuators generally have an input shaft and an output shaft. A reducer uses the energy delivered through the input shaft to generate torque, then transmits that torque to an external device through the output shaft.
Backdrive is the reverse of normal operation, where the motor drives the output shaft through the reducer. Instead, an external force moves the output shaft, and that rotation travels back through the reducer to the motor shaft. Backdrivability, in other words, describes how easily a force applied to the output shaft can travel back toward the input shaft.
This characteristic matters a great deal when a robot interacts with people or its surroundings. High backdrivability lets a joint respond naturally to outside forces, which is why it’s especially valued in applications that call for flexible joint movement, such as collaborative robots, rehabilitation robots, and walking robots.
That said, not every piece of equipment needs high backdrivability. What an actuator requires depends heavily on the task and the operating environment. Logistics loading and unloading equipment, for instance, needs to carry heavy objects reliably at a fixed position, so a rigid structure that holds its load and position steady matters more than a tendency to move easily under outside force.
The Drive Characteristics Required for Humanoid Walking
Backdrivability is a key design factor in humanoid robot development. Every time a bipedal robot’s foot strikes the ground, the resulting impact and load travel through the lower-body joints, including the ankles, knees, and hips. In real-world use, this happens over and over for extended periods, and the burden on those joints only grows once the robot’s own weight is combined with whatever payload it’s carrying.
During walking, backdrivability helps cushion the impact and load reaching the joints, in much the same way the joints and surrounding tissue in the human body absorb outside shock and regulate movement.
If the actuators in major lower-body joints such as the knees and ankles have low backdrivability, the impact generated on landing can pass straight through to the drive unit, creating a heavy load burden. When this kind of stress builds up repeatedly, it can shorten the drive unit’s lifespan and durability and raise the risk of component damage.
Backdrivability alone, however, isn’t enough to achieve stable walking. A humanoid’s joints have to absorb landing impact while also supporting the robot’s weight and payload and executing precise movement.
That calls for weighing factors like the reduction ratio, the motor’s output characteristics, and maximum torque alongside backdrivability itself. In short, an actuator built for humanoid use needs to be evaluated comprehensively, both for how flexibly it responds to impact and for how reliably it can drive the joint.
The BCSA Actuator: A Drive Solution for Bipedal Walking
The BCSA cycloidal actuator is a robot drive solution designed with exactly this kind of humanoid robot development environment in mind. Because a bipedal robot’s joints need to mirror the human body’s structure, it’s essential to be able to fit a variety of components efficiently into a limited joint space.
The BCSA series uses a slim structure that keeps the actuator thin while still delivering high torque. This makes it possible to shrink the actuator’s size and weight and place it efficiently even within tight spaces. The room this frees up can go toward additional sensors, extra functional components, or improved wiring layouts, adding flexibility to the overall system design. For humanoids that rely on a range of sensors to move, that kind of spatial efficiency becomes a real driver of design freedom.
Because a humanoid’s joints have to withstand repeated load and impact while still moving reliably, actuator durability matters just as much. The cycloidal reduction structure inside the BCSA V4 uses a multi-contact design where several tooth profiles engage at once, spreading the load across them. This structural feature helps the actuator deliver the torque a robot needs while reducing the load burden during long, repetitive walking motion, which works in favor of durability.
Alongside the strengths of its cycloidal design, the BCSA also stands out for its pinless structure. By removing the pin components found in a conventional cycloidal design, this pinless cycloidal structure reduces the number of internal parts, simplifying the design and streamlining assembly to boost productivity. Fewer components also means fewer potential points of failure, which is an advantage for maintenance as well.
Taken together, the BCSA’s slim, high-torque design, strong durability, and productivity-boosting pinless cycloidal structure make it an actuator solution well suited to what bipedal robot joints require.
Humanoid development calls for weighing high output performance and drive characteristics alongside the robot’s structure, its operating environment, backdrivability, and a range of other factors all at once. That’s why it’s so important to work with a technology partner who can help review the requirements for core components like actuators from the earliest design stages and recommend the best direction forward.
Drawing on our cycloidal actuator technology, Bonsystems works with customers to review and propose drive solutions suited to their specific development environment. If you need help selecting components during humanoid robot development, or you’d like additional materials on the BCSA actuator, please reach out to us through our website.
FAQ
Q. Why does backdrivability matter so much in humanoid robot development?
A bipedal robot’s joints need to respond to a wide range of changing conditions in order to move the way a person does. Handling landing impact during walking, in particular, requires an actuator that can absorb outside force appropriately. Backdrivability is one of the key factors used to judge this kind of drive characteristic, and it becomes especially important when a robot works alongside people or operates in environments that change frequently.
Q. What advantages can the BCSA actuator offer during humanoid robot development?
Built on a slim structure, the BCSA V4 is designed to deliver high torque even within a tight joint space. This helps make joints smaller and lighter, and the space it frees up can be used for a more efficient system layout, such as placing additional components or an extra battery. It also uses a pinless cycloidal structure that simplifies the internal design, offering benefits for both productivity and maintenance.
Q. What information should I prepare when inquiring about the BCSA V4?
When reaching out about an actuator, it helps to share basic details such as the required torque, reduction ratio, installation space, and intended use, since this speeds up the review process. Because a bipedal robot’s joints can each call for different performance requirements, it’s especially useful to also include where the actuator will be applied, the load conditions involved, and how it will operate.
